Fujitsu LifeBook T902 User Manual

72 - Lithium ion Battery
Low Battery State
When the battery is running low, a low battery notification message will appear. If you do not respond to the low
battery message, the batteries will continue to discharge until they are too low to operate. When this happens, your
Tablet PC will go into Sleep mode. There is no guarantee that your data will be saved once the Tablet PC reaches this
point.
Dead Battery Suspend mode shows on the Status indicator just like the normal Sleep mode. Once your Tablet PC goes
into Dead Battery Suspend mode you will be unable to resume operation until you provide a source of power either
from an adapter, or a charged battery. Once you have provided power, you will need to press the
Power/Suspend/Resume slide to resume operation.
In the Dead Battery Suspend mode, your data can be maintained for some time, but if a power source is not provided
promptly, the Power indicator will stop flashing and go out, meaning that you have lost the data that was not stored.
Once you provide power, you can continue to use your Tablet PC while an adapter is charging the battery.
Shorted Batteries
The Status Indicator panel indicator associated with the Battery Level indicator displays the operating level available
in that battery. If this display shows a flashing red LED, it means the battery is damaged and must be replaced so it
does not damage other parts of your LIFEBOOK Tablet PC.
USING HEAVY CURRENT DEVICES OR FREQUENT EXTERNAL OPTICAL DRIVE ACCESSES MAY PREVENT CHARGING COMPLETELY.
• ONCE THE LOW BATTERY NOTIFICATION MESSAGE APPEARS, YOU NEED TO SAVE ALL YOUR ACTIVE DATA AND PUT YOUR LIFEBOOK TABLET PC INTO
S
LEEP MODE UNTIL YOU CAN PROVIDE A NEW POWER SOURCE. YOU SHOULD PROVIDE A CHARGED BATTERY, AN AC POWER ADAPTER, OR
A
UTO/AIRLINE ADAPTER AS SOON AS POSSIBLE.
• WHEN YOU ARE IN SLEEP MODE THERE MUST ALWAYS BE AT LEAST ONE POWER SOURCE ACTIVE. IF YOU REMOVE ALL POWER SOURCES WHILE YOUR
LIFEBOOK T
ABLET PC IS IN SLEEP MODE, ANY DATA THAT HAS NOT BEEN SAVED TO THE HARD DRIVE WILL BE LOST.

Fujitsu LifeBook T902 Specifications

General

Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Product color	Black, Silver
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-3520M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3500 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	29
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Ambient light sensor	Yes
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Storage media	-
Total storage capacity	- GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	13.3 \
Display brightness	300 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	500:1
On-board graphics card ID	0x166
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Power adapter depth	56 mm
Power adapter width	148 mm
Power adapter height	32 mm
Power adapter weight	250 g
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Keyboard number of keys	85
Bundled software	Adobe Reader
Processor code	SR0MU
Processor ARK ID	64893
Processor package size	37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	6700 mAh
Battery life (max)	7.7 h
Battery recharge time	3 h
Number of battery cells	6
AC adapter power	100 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	5.27 A
AC adapter output voltage	19 V
Cable lock slot type	Kensington
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth	244 mm
Width	326 mm
Weight	1890 g
Height (rear)	31 mm
Height (front)	27.1 mm
