76 - Secure Digital Cards
Installing SD Cards
SD Cards are installed in the SD Card slot. To install an SD Card, follow these steps:
1 See your specific card manual for instructions on the installation of your card. Some cards may require that your
Tablet PC is off while installing them.
2 Make sure there is no card currently in the slot. If there is, see Removing an SD Card below.
3 Insert your card into the slot with the product label facing up.
4 Push the card firmly into the slot until it is seated in the connector.
Removing an SD Card
To remove an SD Card, follow these easy steps:
1 Select Safely Remove Hardware from the System Tray. Highlight the card in the list, then click [Stop].
2 Push the SD Card in until it unlatches. It will then eject from the slot for removal.
INSTALLING OR REMOVING AN SD CARD DURING YOUR LIFEBOOK TABLET PC’S SHUTDOWN OR BOOTUP PROCESS MAY DAMAGE THE CARD AND/OR
YOUR LIFEBOOK TABLET PC.
D
O NOT INSERT A CARD INTO A SLOT IF THERE IS WATER OR ANY OTHER SUBSTANCE ON THE CARD AS YOU MAY PERMANENTLY DAMAGE THE CARD,
YOUR LIFEBOOK TABLET PC, OR BOTH.
S
EE YOUR CARD MANUAL FOR SPECIFIC INSTRUCTIONS ON THE REMOVAL OF YOUR CARD. SOME CARDS MAY REQUIRE YOUR LIFEBOOK TABLET PC
TO BE IN SLEEP MODE OR OFF WHILE REMOVING THEM.

Fujitsu LifeBook T902 Specifications

General

Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Product color	Black, Silver
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-3520M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3500 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	29
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Ambient light sensor	Yes
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Storage media	-
Total storage capacity	- GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	13.3 \
Display brightness	300 cd/m²
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	500:1
On-board graphics card ID	0x166
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Power adapter depth	56 mm
Power adapter width	148 mm
Power adapter height	32 mm
Power adapter weight	250 g
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Keyboard number of keys	85
Bundled software	Adobe Reader
Processor code	SR0MU
Processor ARK ID	64893
Processor package size	37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	6700 mAh
Battery life (max)	7.7 h
Battery recharge time	3 h
Number of battery cells	6
AC adapter power	100 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	5.27 A
AC adapter output voltage	19 V
Cable lock slot type	Kensington
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth	244 mm
Width	326 mm
Weight	1890 g
Height (rear)	31 mm
Height (front)	27.1 mm
