TX100 S3 Operating Manual 53
Starting up and operation
6.2.1.1 Control elements
6.2.1.2 Indicators on the control panel
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button.
When the system is operating, pressing the On/Off button will
switch off the system.
V CAUTION!
Risk of loss of data!
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
Power indicator (green)
Glows green when the server is switched on.
Is dark when the server is switched OFF, but mains voltage is
present (standby mode).
HDD activity indicator (green)
Lights up green when an internal hard disk drive is accessed.
