24 Operating Manual TX140 S1
Functional overview
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3049
Chipset Intel
®
C202
Processor quantity and
type
1x Intel
®
Xeon
®
/Pentium
®
/Core i3 processor
Memory slots 4
Memory slot type DIMM (DDR3)
Memory capacity
(min. - max.)
2 GB - 32 GB
Memory protection ECC
Memory notes 1333 MHz memory modules with 2, 4, or 8GB
USB connectors 10 x USB 2.0 (2x front, 6x rear, 2x internal (USB1
AUX and USB1 DAT connot be used in parallel)
Graphics (15-pin) 1 x VGA
Serial 1 (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet
Service LAN (RJ45) 1 x dedicated service LAN port for iRMC S3
(10/100/1000 Mbit/s) Service LAN traffic can be
switched to shared onboard Gbit LAN port
