2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3239
Chipset Intel
®
C224
Processor quantity and
type
1x Intel
®
Xeon
®
/Pentium
®
/Core i3 processor
Memory slots 4
Memory slot type DIMM (DDR3)
Memory capacity
(min. - max.)
2 GB - 32 GB
Memory protection ECC
Memory notes 1333/1600 MHz memory modules with 2, 4, or 8GB
USB 2.0 connectors 6 (4x external rear, 2x internal for UFM or backup
device, no USB wakeup supported)
USB 3.0 connectors 4 (2x external rear, 2x external front)
Graphics (15-pin) 1 x VGA
Serial 1 (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet
