B. SCSI controller for internal backup drives
S26361-F2399-E2
SCSI 160 Controller
Adaptec SCSI Card 29160
1 channel: LVD + Fast/ Ultra (decoupl.)
LVD connect. for HD, without cable
Fast/Ultra connect. for acc. drives
64/66 PCI, min 180 mm
int: Fast 50-pin or Ultra HD68
+ LVD HD68; ext: HD68(LVD)
SW:
max. 1x per system
S26361-F2814-E6
68-Pin Kit for accessible drives
Cable with Terminator
To connect acc. drives to
separate SCSI controller
max. 1x per system
C. SCSI controller for external drives and peripheral devices
S26361-F2399-E1
Only SX10 Backup is for external
SCSI U160 controller
connection at the SCSI controller.
Adaptec SCSI Card 29160
1 channel: LVD + Fast/ Ultra (decoupl.)
LVD connect. for HD, without cable
Fast/Ultra connect. for acc. drives
64/66 PCI, min 180 mm
int: Fast 50 pol oder Ultra HD68
+ LVD HD68; ext: HD68(LVD)
SW:
max. 1x per system
Section
VIII
Disk Array
D. LSI - Controller
1-channel Ultra 320 SCSI on-board controller with LSI Integrated Mirroring (IME)
Standard SCSI-cabling of a PRIMERGY TX150 S4 basic unit with on-board controller
Ultra 320 SCSI controller is connected to the internal hard disks and internal backup devices,
if no additional HD/backup device controllers are configured.
1x per PRIMERGY TX150 S4
D. zero-channel RAID controller (320-0x) for internal Disk Array
and additional RAID controllers for internal / external Disk Array
S26361-F3085-E128
0-channel RAID controller
LSI
320-0x
128MB SDRAM ECC Cache
BBU optional
Zero channel RAID controller
in combination with on-board
LSI must be installed in the
U320 SCSI controller blue marked bay.
without cable
64Bit/133MHz PCI-X controller
With zero channel RAID controller
3.3V power supply & signaling the IME function is no longer
max. 1x per system
available.
S26361-F3085-E10
Cache Battery Backup Unit
max. 1x pro Controller
to be
continued
on next page
H
max. 4x
Fujitsu Siemens Computers
Enterprise Products - PRIMERGY Server
13 of 18
