1x PCI-X 66 long (3,3V)
1x PCI-X 66 (3,3V) ZCR Slot
1x long / 2x short 32Bit / 33MHz (5V)
* 4 memory slots for up to 8GB (PC4200) registered DDR II RAM (ECC), max. 2GB modul per slot
* 1 drive bay 3.5" occupied by 1 floppy disk 1.44MB 1" height (optional)
* 3 Einbauplätze 5,25" für bedienbare Laufwerke
* 4 bays 1" for hot plug SCSI HD)
* ATI Range XL Graphic controller 8MB
* Intel Broadcom (5721) 10/100/1000 Mb/s on-board
* 1 x Fast-IDE (ATA) Controller on-board (for 1x 2 devices)
* 1-channel Ultra 320 SCSI Controller LSI 1020A on-board
with HW RAID IME (IME = Integrated Mirroring Enhanced)
Options:
* Hot plug PS or a second redundant hot plug PS version can be configured by ordering the
appropriate upgrade option
* LSI Zero Channel RAID option, simultaneous use of HD and Tape Drive possible
Cables:
1. IDE cable for CD/DVD
2. With SCSI variant wide LVD SCSI cable for connection of the HD backplane and two
accessible drives
PS/2 mouse (only for floorstand version)
ServerStart packet incl. ServerBooks CD, ServerSupport CD and ServerView
External Interfaces:
2x RS-232-C (serial, 9 pins)
1x Centronics (parallel, 25 pins, EPP/ECP compatible)
1x keyboard (PS/2)
1x mouse (PS/2)
1x VGA (15 pins)
1x USB 2.0 on front and 2x USB 2.0 on rearside
1x LAN RJ45
