Getting to Know Your STYLISTIC
Front and Back Side Panel Components
Release Button
To release the Tablet PC from the cradle.
*Optional Accessory
1.
(This picture is for illustration purpose only and may look different from the actual unit)
USB 3.1 (Gen 1) Connector
USB 3.1 (Gen 1) Connector
VGA Port
HDMI Port
LAN Port
Kensington Lock
DC Power Jack
2.
3.
4.
5.
6.
7.
8.
STYLISTIC Q509 with Optional Accessories
Cradle*
3
2
4
5
6
7
8
To Next Page
