Fujitsu STYLISTIC Q509 User Manual

13
Connecting the AC Adapter
Connecting the AC Adapter
The AC adapter provides power for operating
your Tablet PC and Charging the batteries.
Connecting the AC Adapter
1. Plug the DC output cable into the DC-in of
your Tablet PC.
2. Plug the AC adapter into an AC electrical
outlet.(Above Figure)
Switching from AC Adapter Power to Battery
Power
1. Be sure that you have a charged battery
installed.
2. Remove the AC adapter.
The Lithium ion battery is not charged
upon purchase. Initially, you will need to
connect the AC adapter to use your Tablet
PC.
DC Output Cable
DC Power Plug
AC Adapter
AC Cable
Power Sources
Your Fujitsu STYLISTIC Q509 has two possible
power sources: a primary Lithium ion battery
and an AC adapter.
Using Your STYLISTIC
