46 Installation and operating manual “1350-EN”
Heat pump, Split, single service
4 Configuring the installation
F
Optional DHW kit
DHW tank control (with electrical back-up) requires
the use of the DWH kit.
Warning: The tank must be fitted with an electric
back-up, particularly for anti-legionella cycles.
Please refer to section (Operating principle, page 13)
F
Optional 2nd circuit kit
The control of 2 heating circuits requires the
installation of the 2nd circuit.
If the installation consists of radiators (or
fan-convectors) and a heated floor, zone 2 will
correspond to the radiator (or fan-convectors) zone
and zone 1 to the heated floor zone.
F
Optional boiler connection kit
The connection of an oil or gas boiler to the heat
pump requires the installation of the boiler
connection kit.
When a boiler is connected to the heat pump, the
heat pump’s electric back-ups must not be
connected. It is the boiler that provides the
heating back-up on the coldest days.
The boiler is controlled by the heat pump.
Please refer to the instructions supplied with the
boiler connection kit.
F
Swimming pool kit option
Please refer to the instructions supplied with the
swimming pool kit.
Configuration
(Parameter 5700)
Type of installation Page
Pre-setting 1
1 heating circuit 48
Pre-setting 2
1 heating circuit and DHW tank 49
Pre-setting 3
2 heating circuits 50
Pre-setting 4
2 heating circuits and DHW tank 51
Pre-setting 5
Boiler connection and 1 heating circuit
Please refer to the
instructions supplied
with the boiler
connection kit.
Pre-setting 6
Boiler connection and 2 heating circuits
Pre-setting 7
Boiler connection, 1 heating circuit and DHW tank
Pre-setting 8
Boiler connection, 2 heating circuits and DHW tank
Pre-setting 9
Do not use for heat pump single service. Reserved only for heat pump 2 services
Pre-setting 10
Pre-setting 11
Pre-setting 12
F
Please consult us regarding any other installation configuration.
