CAUTION
Observe the following compass safe
distances to prevent deviation of a
magnetic compass:
Note: For more information, please refer to
IMO SN/Circ.271 “Guidelines for the
installation of shipborne radar equip-
ment.”
Standard
compass
Antenna Unit
Processor Unit
Monitor Unit
Power Supply
Unit
ECDIS Control
Unit
Radar Control
Unit
Trackball Control
Unit
Switching Hub
Intelligent HUB
Sensor Adapter
Steering
compass
Type
EC-3000
MU-190
MU-231
PSU-014
RCU-024
RCU-025
RCU-026
(HUB-100)
HUB-3000
MD-3000S
MD-3010A
MD-3020D
MD-3030D
3.05 m 1.90 m
2.40 m
1.65 m
0.85 m
2.20 m
0.30 m
0.30 m
0.30 m
1.00 m
1.20 m
2.05 m
0.75 m
1.05 m
0.90 m
1.55 m
1.05 m
0.55 m
1.40 m
0.30 m
0.30 m
0.30 m
0.60 m
0.75 m
1.35 m
0.50 m
0.70 m
0.60 m
RSB-129
PSU-015
1.45 m 0.90 m
Do not open the equipment
unless totally familiar with
electrical circuits and service
manual.
Only qualified personnel are
allowed to work inside the
equipment.
WARNING
ELECTRICAL
SHOCK
HAZARD
Construct a suitable service
platform from which to install the
antenna unit.
Serious injury or death can result if
someone falls from the radar antenna
mast.
Turn off the power at the mains
switchboard before beginning the
installation.
Fire, electrical shock or serious injury
can result if the power is left on or is
applied while the equipment is being
installed.
Be sure that the power supply is
compatible with the voltage rating
of the equipment.
Connection of an incorrect power
supply can cause fire or damage the
equipment.
Use only the specified power
cable.
Fire or damage to the equipment can
result if a different cable is used.
Do not install the monitor unit,
processor unit, power supply unit
(PSU), or control unit in a dusty
environment, or one where the
units may get wet from rain or
water splash.
Dust or water in the units can result in
fire, electrical shock, or damage to
the equipment.
Attach protective earth securely to
the ship's body.
The protective earth (grounding) is
required for the AC power supply to
prevent electrical shock.
