1
1. OPERATIONAL OVERVIEW
1.1 Controls
Press once: Zoom, centering,
or escapes from current opera-
tion, depending on display in
use.
Press twice: Opens menu.
Chooses display mode.
Momentary press: Turns
power on. With the power on, press
to adjust dimmer and contrast.
Long press: Turns power
off.
Momentary press: Inscribes mark.
Long press: Inscribes MOB mark.
Sets/cancels destination.
Registers items on menus.
Cursor Pad
• Shifts cursor (cursor displayed)
and display (cursor off).
• Selects items on menus.
• Enters alphanumeric data.
MENU
DIM
PWR
MARK
MOB
ENT
DISP
GOTO
Control panel
How to attach and remove the hard cover
To attach the hard cover, set it to the display unit at an angle.
To remove the hard cover, do as follows:
Press at arrows
and pull toward
you to remove.
