11
ADJUSTING SUB-WOOFER LEVEL AND TONE
Use the Sub level and Tone screens to set the sub-woofer levels and tone.
Sub-woofer level can be adjusted for each Zone individually, but tone
adjustments affect all Zones.
Menu key Encoder
To set sub-woofer levels or tone:
1. Press and hold down the Encoder for at least one second. The Sub level
screen is displayed.
2. Turn the Encoder to adjust the sub-woofer level for the highlighted Zone, as
required.
3. Press the Encoder to highlight the next Zone, and adjust as required. When
you press the Encoder in the last Zone, the Tone screen is displayed.
60
SUPPORT, SALES AND SERVICE
FUSION Electronics in New Zealand + 64 9 369 2900
FUSION Electronics Australia + 61 1300 736 012
FUSION Electronics Europe +31 76 572 3632
FUSION Electronics USA +1 623 580 9000
Website: www.fusionelectronics.com
SPECIFICATIONS
FCC compliance statement
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
• this device may not cause harmful interference, and
• this device must accept any interference received, including interference
that may cause undesired operation.
General specifi cations
Operating voltage ......................................10.2–16 VDC negative ground
Fuse rating .....................................................15 amp
DVD player
Laser power ..................................................Class I
Power output
Maximum .........................................................70 W x 4
26 WRMS per channel at 4 ohms
45 WRMS per channel at 2 ohms
Pre-output voltage ....................................3 VRMS
Auxiliary input sensitivity
The 700 Series AUX input sensitivity is 1V RMS when gain is set to
0dB.
• Increasing the gain by 6dB doubles the input sensitivity (0.5V RMS for
same volume).
