Gardena PowerMax 1200/32 User Manual

To x the cable to the handle
8
7
8
7
1. Fix the cable (7) to the handle with the clip (8).
2. Check that the cable (7) is not trapped between the
lower and the upper handle.
To assemble the grass box
9
11
10
10
11
9
G1
G2
1. Only for PowerMax 1400/34 : Connect both parts
(G1)/(G2) of the grass box until the connections click.
Make sure that all connections are connected.
2. Push the chute (9) into the grass box until it clicks.
3. Turn the cover (10) on the grass box.
Make sure that the cover (10) aligns to the grass
box.
4. Push the cover (10) on the grass box until the
connections click.
Make sure that all connections are connected.
5. Push the handle (11) into the cover (10) until it clicks.
16 - 001 -
21

Gardena PowerMax 1200/32 Specifications

General

Power	1200 W
Cutting Width	32 cm
Cutting Height	20-60 mm
Cutting Height Steps	10
Grass Box Capacity	30 l
Weight	8.3 kg
Power Source	Electric
