Garland Master Series Installation And Operation Manual

Part 1382606 Rev 2 (12/07) Page 9
TROUBLE SHOOTING
PROBLEM PROBABLE CAUSE CORRECTIVE ACTION
CORRECTIVE ACTION BY
SERVICEMAN
Filter Heat Switch does not
glow
Unit unplugged Plug in cord set. Same
Loose wire. None Replace wire
Defective switch None Replace defective switch.
Filter Heater will not heat Pan not in place. Push pan in until contacts
“make”
Same
Defective heater switch None Replace defective switch.
Defective On-O switch None Replace defective switch
Defective Pan heater None Replace defective heater.
Filter Pump will not pump Filter holder not properly
connected at pump
Make proper connection Same
Shortening solidied in lter
pan
Leave lter heater on at night
when using solid shortening
Same
Pump actuator micro
switch defective or out of
adjustment
None Adjust or replace as
necessary
Pump relay defective None None
Pump coupling “O” ring
missing
Replace “O” ring. Same
Filter Power Shower not
spraying properly
Stoppage in Power Shower
tubing
Clean Same
Filter holder not properly
connected at pump
Make proper connection Same
Shower assembly not
connected
Make proper connection Same
O-Ring lost or defective Replace Same
Drain tubing Leaking. Defective gasket Replace gasket. Same
Loose connection Tighten connection Same
