Apollo SL30 Installation Manual

APOLLO SL30 POST-INSTALLATION CHECKOUT LOG

Date: ___/___/___

By: _____________

CONFIGURATION INFORMATION:

SL30 NAV/COMM 430-6040-3_____ Mod ____ Serial # ___________

TEST MODE CHECKOUT AND SETUP:

Avionics Outputs:

[ ] Resolver [ ] Converter [ ] Serial [ ] None

[ ] Calibration (if Resolver)

[ ] Control Test

[ ] Display Test

[ ] NAV Valid flag [ ] GS Valid flag

[ ] TO/FROM flag (OFF, TO, FROM)

[ ] External annunciator (BC)

[ ] CDI (left, mid, right)

[ ] GS (up, mid, down)

[ ] Enable Weather Freq Yes ___ No___ [ ] Enable DST Display Yes ___ No___

VHF NAV CHECKOUT:

VOR reception with ground equipment

[ ] Audio and Morse code ID functions

[ ] Verify CDI NAV and GSI GS flags

VHF COMM CHECKOUT:

[ ] Receiver / Transmitter operation [ ] Sidetone level set / checked

[ ] Antenna check [ ] Transmit Mic selection

[ ] Remote flip/flop input

FINAL SYSTEM CHECK:

[ ] RS-232 inputs/outputs checked (Optional)

[ ] Comm Operation

[ ] VOR Check

[ ] Station ID

[ ] TO/FR [ ] ILS Check

[ ] Left/Right (CDI) [ ] Station ID

[ ] Valid Flag (NAV) [ ] Valid Flags (NAV/GS)

[ ] Radial (To/From) [ ] Left/Right (CDI)

______Bearing Error [ ] Up/Down (GSI)

[ ] Remote Flip/Flop input [ ] BC Function (Annunciator)

COMMENTS:
