Composite Video Considerations
This chartplotter allows video input from composite video sources using the port labeled CVBS IN. When
connecting composite video, you should observe these considerations.
• The CVBS IN port uses a BNC connector. You can use a BNC to RCA adapter to connect a composite-video
source with RCA connectors to the CVBS IN port.
• Video is shared across the Garmin Marine Network, but it is not shared across the NMEA 2000 network.
Specifications
All Models
Temperature range From -15° to 50°C (from 5° to 122°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating IEC 60529 IPX7
1
Input voltage From 10 to 32Vdc
Fuse 6A, 125V fast-acting
NMEA 2000 LEN @ 9Vdc 2
NMEA 2000 draw 75mA max.
Compass-safe distance 65cm (25.5in.)
Memory card 2 SD
®
card slots; 32GB max. card size
Wireless frequency, transmit power 2.4GHz @ 15.26dBm maximum
10x2 Models
Dimensions (W x H x D) 31.8 x 18.5 x 6.9 cm (12.5 x 7.3 x 2.7 in.)
Display size (W x H)
22.4 x 12.5 cm (8.8 x 4.9 in.)
10.1 in. diagonal
Weight 1.85kg (4.1lb.)
Max. power usage at 10Vdc 32.4W
Typical current draw at 12Vdc 1.9A
Max. current draw at 12Vdc 2.7A
12x2 Models
Dimensions (W x H x D) 35.8 x 22.6 x 6.9 cm (14.1 x 8.9 x 2.7 in.)
Display size (W x H)
26.2 × 16.3 cm (10.3 × 6.4 in.)
12.1 in. diagonal
Weight 2.34kg (5.15lb.)
Max. power usage at 10Vdc 34.8W
Typical current draw at 12Vdc 2.2A
Max. current draw at 12Vdc 2.9A
1
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
13
