Removing the doors.
30
Before Removing the Doors
Unplug the refrigerator from its electrical outlet.
Empty all door shelves, including the dairy compartment.
CAUTION: Do not let either door drop to the floor. To do so could
damage the door stop.
2
1
Read these instructions completely and carefully.
Remove the Freezer Door on Non-Dispenser Models
Tape the door shut with masking tape.
With a Phillips screwdriver, remove the hinge cover on top of the freezer
door (on some models).
Lift the hinge straight up to free the hinge pin from the socket in the
top of the door.
Remove the tape and tilt the door away from the cabinet. Lift it off the
bottom socket.
Set the door on a non-scratching surface with the outside up.
5
4
3
2
1
