GE 600 - 1500 VA User Manual

OPM_NPE_19X_600_1K5_2GB_V030 1 GE DE NetPro 19” 600-1500: User manual 3.0 (GB)
g
GE Digital Energy
USER MANUAL
NetPro 19"
Uninterruptible Power Supply
Uninterruptible Power SupplyUninterruptible Power Supply
Uninterruptible Power Supply
600 - 1500 VA
600 - 1500 VA600 - 1500 VA
600 - 1500 VA
Please read these instructions carefully before installation and start-up of the
NetPro 19” UPS. Keep this manual in a safe place for future reference.
CONTENTS
1 INTRODUCTION.............................................................................................2
1.1 Introduction
1.2 Safety Rules
1.3 Transport / Storage
2 INSTALLATION...............................................................................................2
2.1 Installation Rules
2.2 Installation Procedure
3 OPERATION...................................................................................................4
3.1 Start-up
3.1.1 Start-up, mains available
3.1.2 Start-up, mains not available (‘battery start’)
3.2 Use: Normal Operation
3.2.1 Normal operation conditions
3.2.2 Load indication
3.2.3 Auto-off (no-load shutdown)
3.2.4 Automatic bypass switch
3.2.5 Switching off
3.3 Use: Status and Alarm Indications
3.3.1 Charger on
3.3.2 On-line: normal operation
3.3.3 On battery
3.3.4 Battery low (end of runtime)
3.3.5 On bypass
3.3.6 Bypass out of limits
3.3.7 Overload
3.3.8 Overtemperature
3.3.9 Replace battery
3.3.10 Programmed shutdown
3.4 Use: Setup Mode
3.5 Battery Management
4 COMMUNICATION .........................................................................................9
4.1 RS232 Port
4.2 Relay Interface Card (option)
4.3 SNMP Interface Card (option)
5 OPTIONAL FEATURES................................................................................10
5.1 Extended Runtime (NetPro 19” 1000)
5.2 PowerFLAG SerVICe Box for Modem Connection
6 MAINTENANCE ............................................................................................10
6.1 General
6.2 Batteries
6.2.1 General
6.2.2 Battery Replacement
7 TROUBLESHOOTING..................................................................................12
8 SPECIFICATIONS ........................................................................................13
©
GE Digital Energy
. All rights reserved; reproduction in whole or in parts without permission is prohibited. This manual may be
subject to change; no liability can be accepted for any error or omission.
GB

GE 600 - 1500 VA Specifications

Power Ratings

voltage amperes	600 1000 1500 VA
watts with resistive load	360 600 900 W
input thermal circuit breaker	5 5 7 A
input fuse	8 8 10 A

Input Converter

ac input voltage	220 - 240 V
ac input voltage range at 100% load	187 - 264 V
ac input voltage range at 70% load	120 - 264 V
minimum start-up ac voltage	187 V
input current at nominal input voltage	2.0 3.3 5.0 A
input frequency range	45 - 66 Hz

Output Converter

ac output voltage	230 V
ac output voltage tolerance	± 2%
output frequency	50 or 60 Hz
output frequency range	nominal ± 0.15%
harmonic distortion	< 2%

Bypass

ac input voltage range	195 - 264 V
frequency tracking rate	2 Hz/sec.
frequency tracking range	nominal ± 10%
phase difference	< 7º
typical transfer time	4 msec

Batteries

nominal voltage	24 36 48 Vdc
number of 7 Ah batteries	2 3 4
recharge current	1.5 A
battery recharge time for 90% capacity	1.5 hours
runtime at typical load 75%	12 12 10 minutes

Operating Environment

ambient temperature	-10 to +40ºC
audible noise at 1 meter	< 45 dB(A)
max relative humidity	95%

Weight and Dimensions

weight without battery drawer	14 kg
weight with battery drawer	19 22 24 kg
dimensions	133.5 x 450 x 440 mm
depth required in 19” rack	420 mm
