Trim kits and decorator panels.
Read these instructions completely and carefully.
Before You Begin
Some models are equipped with trim kits that allow you to install door panels. You can order
pre-cut black or white decorator panels from GE Parts and Accessories, 800.626.2002, or you can
add wood panels to match your kitchen cabinets.
Panels less than 1/4
″
(6 mm) thick
When installing wood panels less than 1/4″ (6 mm) thick, you need to create a filler panel, such as 1/8″
cardboard, that will fit between the face of the door and the wood panel. If you are installing the pre-cut
decorator panels, pre-cut filler panels are included in the kit. The combined thickness of the decorator
or wood panel and the filler panel should be 11/32″ (8.7 mm) with the panel itself being no larger than
1/4″ (6 mm).
For panel required models
Panels 1/4″ thick or less
1/4″ max
The handle and the top and bottom trim stand in front of the surface of the door, which requires that the
filler be smaller in length and width than the panel. Use the guidelines below and tape the filler onto the
back of the panel.
Left Fresh Food Door
Freezer Door
Filler
2 1/2″ (63.5 mm)
3/4″ (19 mm)
3/4″ (19 mm)
Panel
Filler
2 1/2″ (63.5 mm)
3/4″ (19 mm)
Panel
Right Fresh Food Door
Filler
2 1/2″ (63.5 mm)
3/4″ (19 mm)
3/4″ (19 mm)
Panel
