APPENDIX
Display Default CONF Description
Menu MAIN
PU / SU / F -
In.1 - Input IN 1 main
In.2 - Input IN 2 main
In.3 - Input IN3 auxiliary
In.4 - Input IN4 auxiliary
Fin.A - Result math function A
Fin.b - Result math function b
AL.1 100 Alarm 1 setpoint
AL.2 200 Alarm 2 setpoint
AL.3 300 Alarm 3 setpoint
AL.4 400 Alarm 4 setpoint
AL.5 500 Alarm 5 setpoint
AL.6 600 Alarm 6 setpoint
AL.7 700 Alarm 7 setpoint
AL.8 800 Alarm 8 setpoint
AL.9 900 Alarm 9 setpoint
AL.10 1000 Alarm 10 setpoint
Menu
IInnff
Upd - Software release
(od - Instrument code
Err.1 - Error code for IN1
Err.2 - Error code for IN2
Err.3 - Error code for IN3
Err.4 - Error code for IN4
Err.5 - Error code for Fin. A
Err.6 - Error code for Fin. b
dps.s - Decimal point position Fin. A
dps.6 - Decimal point position Fin. b
Lo.S.5 - MIN scale limit Fin. A (read only)
Lo.S.6 - MIN scale limit Fin. b (read only)
xiS.S - MAX scale limit Fin. A (read only)
xiS.6 - MAX scale limit Fin. b (read only)
Upd.F - Fieldbus software version
(od.F - Fieldbus instrument code (read only)
bAv.F - Set fieldbus baudrate (read only)
Menu
SSEErr
(od 1 Instrument code
bAv 4 Serial communication baudrate
Par 0 Serial communication parity
Menu
IINNPP11
typ.1 14 Type of probe or signal for input IN1
Flt.1 0.1 Digital filter input IN1
dPS.1 0 Decimal point position for IN1
LoS.1 0 Min. scale limit input IN1
xiS.1 3500 Max. scale limit input IN1
0fS.1 0.0 Offset input IN1
SG0F.1 0.000 Offset input IN1 calibrated 40mV
SGSE.1 4.000 Sensitivity input IN1 calibrated 40mV
Menu
IINNPP22
typ.2 0 Type of probe or signal for input IN2
Flt.2 0.1 Digital filter input IN2
dPS.2 0 Decimal point position for IN2
LoS.2 0 Min. scale limit input IN2
xiS.2 1000 Max. scale limit input IN2
0fS.2 0 Offset input IN2
SG0F.2 0.000 Offset input IN2 calibrated 40mV
SGSE.2 4.000 Sensitivity input IN2 calibrated 40mV
Menu
IINNPP33
typ.3 1 Type of probe or signal for input IN3
Flt.3 0.1 Digital filter input IN3
dPS.3 0 Decimal point position for IN3
LoS.3 0 Min. scale limit input IN3
xiS.3 1000 Max. scale limit input IN3
0fS.3 0 Offset input IN3
