gefran VDL200 Series Installation And Commissioning Manual

Replace AGy-L by VDL200 Pag. 15 of 17
5.5 Set the speeds system (low, high and inspection)
5.5.1 Multispeed correspondence table AGy-L / VDL200
AGY-L
Multispeed S2 sel /
Terminal 6
Multispeed S1 sel /
Terminal 7
Multispeed S0 sel /
Terminal 25
Multispeed Param Notes
0
0
0
Multispeed 0
S.200
Low Speed (as default)
0
0
1
Multispeed 1
S.201
High Speed (as default)
0
1
0
Multispeed 2
S.202
0
1
1
Multispeed 3
S.203
1
0
0
Multispeed 4
S.204
1
0
1
Multispeed 5
S.205
1
1
0
Multispeed 6
S.206
1
1
1
Multispeed 7
S.207
VDL200
Multispeed S2 sel /
Terminal 3
Multispeed S1 sel /
Terminal 4
Multispeed S0 sel /
Terminal 5
Multispeed Param Notes
0
0
0
Multispeed 0
11020
Low Speed (as default)
0
0
1
Multispeed 1
11022
High Speed (as default)
0
1
0
Multispeed 2
11024
Inspection Speed (as default)
0
1
1
Multispeed 3
11026
1
0
0
Multispeed 4
11028
1
0
1
Multispeed 5
11030
1
1
0
Multispeed 6
11032
1
1
1
Multispeed 7
11034
Copy AGy-L PAR into
VDL200 PAR
AGy-L
VDL200
not
available
PAR 11002
Set to 2Hz
S.200
PAR 11020
(Low Speed)
S.201
PAR 11022
(High speed)
not
available
PAR 11024
(Inspection
Speed)
03 STARTUP WIZARD
Set application par?
E=Yes Down=Next
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
E
SEQ
01 PAR: 11002
Spd unit of measure
Hz
Def: 0
rpm
m/s
E

SEQ
02 PAR: 11020
Multispeed 0
5 Hz
Def: 5
E
SEQ
02 PAR: 11020
Multispeed 0
000000005 Hz
Def: 5
6 Hz
4 Hz
E

SEQ
03 PAR: 11022
Multispeed 1
45 Hz
Def: 45
E
SEQ
03 PAR: 11022
Multispeed 1
000000045 Hz
Def: 45
46 Hz
44 Hz
E

SEQ
04 PAR: 11024
Multispeed 2
20 Hz
Def: 20
E
SEQ
04 PAR: 11024
Multispeed 2
000000020 Hz
Def: 20
21 Hz
19 Hz
E
