KEYPAD CONTROLS & INDICATORS
Window. Displays system status
messages, zone descriptions,
etc
STATUS Light. Lights (green) to
indicate that the system is ready
for arming. If a zone is not
secured the light will be off and
the zone will display in the
window. If a zone has been
bypassed, the STATUS light will
blink while armed.
ARMED Light. Lights (red) to
indicate that the system is
armed. If an alarm has occurred,
the ARMED LED will be flashing.
FUNCTION Button. Selects
available system functions as
displayed in the window. The
selected function is executed by
pressing the Jto button.
BYPASS Button. (1)Deactivates
selected zones from the system.
(2)Unbypasses a bypassed
zone.
RESET Button. (1) Resets
various system troubles,
displays, etc. (See text.) (2)
Resets residential smoke
detectors.
Numerical Keys (1-9, 0). Used
to enter codes, zone numbers,
etc.
ON/OFF Button. Entry key.
Causes the entered code or
selected function to be executed
INTERIOR Button. (1) Bypasses
all Interior Zones simultaneously
to allow free movement within
the premises. (2) Scrolls the
window display forward (NEXT).
(3) Answers “YES” to questions
in the window display.
INSTANT Button. (1) Cancels
entry delay on Exit/Entry Zones,
causing an instant alarm upon
violation. (2) Scrolls window
display backward (PRIOR). (3)
Answers “NO” to questions in the
window display.
AREA Button (G). Selects
other areas and is used with
emergency buttons.
Emergency Buttons. Used with
the G button to signal an
emergency, as follows:
Fire Emergency
Press the 7 and G buttons.
Auxiliary Emergency
Press the 8 and G buttons
Police Emergency
Press the 9 and G buttons.
