English 7
AMPLIFIER SECTION
Bass amplifier output power with an 8 Ohm load: 40 W
Treble amplifier output power with an 8 Ohm load: 40 W
Long term output power is limited by driver unit protection
circuitry.
_____________________________________________
Amplifier system distortion at nominal output:
THD < 0.05 %
SMPTE-IM < 0.05 %
CCIF-IM < 0.05 %
DIM 100 < 0.05 %
_____________________________________________
Signal to Noise ratio, referred to full output:
Bass > 100 dB
Treble > 100 dB
_____________________________________________
Mains voltage: 100, 120, 220 or 230 V
according to region
Voltage operating range: ±10 %
Power consumption:
Idle 10 VA
Full output 80 VA
SYSTEM SPECIFICATIONS
Lower cut-off frequency, –3 dB: < 55 Hz
_____________________________________________
Upper cut-off frequency, –3 dB: > 21 kHz
_____________________________________________
Free field frequency response of system:
58 Hz – 20 kHz (± 2.0 dB)
_____________________________________________
Maximum short term sine wave acoustic output on axis in
half space, averaged from 100 Hz to 3 kHz:
@ 1 m > 100 dB SPL
@ 0.5 m > 106 dB SPL
_____________________________________________
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by driver unit
protection circuit): @ 1 m > 97 dB SPL
_____________________________________________
Maximum peak acoustic output per pair on top of
console, @ 1 m distance with music material: > 108 dB
_____________________________________________
Self generated noise level in free field @ 1 m on axis:
< 10 dB (A-weighted)
_____________________________________________
Harmonic distortion at 85 dB SPL @ 1 m on axis:
Freq: 50…100 Hz < 2 %
>100 Hz < 0.5 %
_____________________________________________
Drivers: Bass 130 mm (5") cone
Treble 19 mm (
3
/
4
") metal dome
Both drivers are magnetically shielded
_____________________________________________
Weight: 5.6 kg (12.3 lb)
_____________________________________________
Dimensions: Height 299 mm (11
13
/
16
”)
(including Iso-Pod™ table stand)
Height 285 mm (11
1
/
4
”)
(without Iso-Pod™ table stand)
Width 189 mm (7
7
/
16
")
Depth 178 mm (7”)
CROSSOVER SECTION
Connectors: Input: XLR female, balanced 10 kOhm,
pin 1 gnd, pin 2 +, pin 3 -
Output: XLR male, balanced 100 Ohm,
pin 1 gnd, pin 2 +, pin 3 -
_____________________________________________
Input level for 100 dB SPL output at 1 m:
-6 dBu at volume control max
_____________________________________________
Volume control range: -80 dB relative to max output
Output signal level is 0 dB relative to input signal level
but adjustable by volume control
_____________________________________________
Crossover frequency, Bass/Treble: 3.0 kHz
_____________________________________________
Treble Tilt control operating range:
0 to –2 dB @ 15 kHz
_____________________________________________
Bass Roll-Off control operating in a –6 dB step @ 85 Hz
(to be used in conjunction with a 7050B subwoofer)
_____________________________________________
Bass Tilt control operating range in –2 dB steps:
0 to –6 dB @ 100 Hz
_____________________________________________
The ‘CAL’ position is with all tone controls set to ‘off’ and
the input sensitivity control to maximum (fully clockwise).
EC DECLARATION OF CONFORMITY
This is to certify that the Genelec Monitoring System
8030A conforms to the following standards:
Safety: EN 60065: 2002 + A1:2006 + A11:2009/
IEC 60065:2001 7th Edition + A1: 2005
EMC: EN 55020 A2: 2008
EN 55013: (2001)+ A1 : 2003 + A2: 2009
EN 61000-3-2: 2006
EN 61000-3-3 A2: 2005
The product herewith complies with the requirements of
The Low Voltage Directive 2006/95/EC and EMC Directive
2004/108/EC
Signed:
Ilpo Martikainen
Position: Chairman of the Board
Date: 12-January-2009
