Owner’s Manual for Stationary Emergency Generators 27
Section 5 Maintenance
5.1 — Component Locations
The side of the enclosure with the viewing window is identified as the rear of the generator set. The right and left sides
are identified by standing at the rear and looking towards the front of the unit.
NOTE: The 2.4L (32 kW) unit is depicted in the artwork used in this manual. The location and appearance of
some components may vary between engine models.
Figure 5-1. Rear View
Figure 5-2. Right Side View
Main Circuit Breaker
Viewing
Window
Control Panel
and LCD Screen
7.5 Amp Fuse
and USB Port
Right SideLeft Side
Oil Level
Dipstick
Oil Filter
Timing Belt
Oil Fill Cap
Air Filter Element
To Next Page
