Owner’s Manual for Stationary Emergency Generators 11
Section 3 Activation and Startup
3.1 — Orientation
NOTE: The 2.4L (32 kW) unit is depicted in the artwork used in this manual. The location and appearance of
some components may vary between engine models.
The side of the enclosure with the viewing window is identified as the rear of the generator set. The right and left sides
are identified by standing at the rear and looking towards the front of the unit.
Figure 3-1. Enclosure (Rear Left View)
3.2 — Remove Side Access Panels
NOTE: Access panels are located at both the left and right sides of the enclosure.
1. Remove key from bag attached to door of unit.
2. Insert key into latch and rotate counterclockwise 1/2 turn. See Figure 3-2.
3. Raise panel using thumb latch.
Figure 3-2. Access Panel Key
