Maintenance
Owner’s Manual for Stationary Emergency Generators 39
Figure 5-12. Check Accessory/Drive Belt Deflection
5.7.11— Replace Air Filter Element
1. Remove wing nut, lock washer and flat washer from threaded rod to release air cleaner cover. See Figure 5-13
2. Remove the air filter element and discard.
3. Thoroughly clean air cleaner cover of any dust, dirt, or debris.
4. Place new air filter element against adapter flange.
NOTE: The air filter element is not directional.
5. Install air cleaner cover over threaded rod. Install flat washer, lock washer and wing nut. Tighten wing nut until
snug.
Belt Deflection Gauge
Alternator Pulley
Water Pump Pulley
2.4L: Manual Adjustment
1.5L: Manual Adjustment 5.4L: Automatic Adjustment
Automatic Tensioner
