Generac Power Systems XP8000E User Manual

Diagnostic Repair Manual 39
Section 6 Major Disassembly
Introduction
Each generator model has a unique method of disassembly. Figure 6-1 is a simplified version of disassembly that does
not go into step by step instructions. The figure below represents the basic disassembly and sequence of steps needed
to remove the fuel tank, stator, rotor, and the engine.
Figure 6-1. Typical Disassembly Steps
004974
