General ASG18ABAJ User Manual

- 35 -
2004.10.19
PARTS LIST
ASG18ABAJ, ASG18RBAJ
ASG24ABAJ, ASG24RBAJ
ASG30RBAJ
ASG24ABAJ
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
34 Capacitor (Fan Motor) 9704305060 9704305060 9704305060 9704305060 9704305060
40 Water Seal Plate 9369684005 9369684005 9369684005 9369684005 9369684005
45 Bracket (Eva. ) 9369372001 9369372001 9369372001 9369372001 9369372001
61 Decoration Plate-G 9368756017 9368756017 9368756017 9368756017 9368756017
63 Front Panel 9368540012 9368540012 9368540012 9368540012 9368540012
69 Louver 9368560010 9368560010 9368560010 9368560010 9368560010
69-1 Louver Base-A 9368558017 9368558017 9368558017 9368558017 9368558017
69-2 Louver Base-B 9368559014 9368559014 9368559014 9368559014 9368559014
74 Air Filter 9368552008 9368552008 9368552008 9368552008 9368552008
92 Link Holder 9368563004 9368563004 9368563004 9368563004 9368563004
108 Base Assy 9369209017 9369209017 9369209017 9369209017 9369209017
122 Bearing Assy 9368574000 9368574000 9368574000 9368574000 9368574000
127 Drain Hose 9367695003 9367695003 9367695003 9367695003 9367695003
146 Evaporator Assy 9369220005 9369220005 9369220005 9369220005 –––––
146-1 Evaporator-A Assy ––––– ––––– ––––– ––––– 9369366000
146-2 Evaporator-B Assy ––––– ––––– ––––– ––––– 9369373008
158 Joint Pipe Assy 9369242007 9369242007 9369242007 9369242007 9371341019
160 Front Drain Pan Assy 9369200014 9369200014 9369200014 9369200014 9369200014
160-1 Rear Drain Pan Assy 9369201011 9369201011 9369201011 9369201011 9369201011
163-2 Thermistor Spring-A 313728262708 313728262708 313728262708 313728262708 313728262708
164 Fan Motor Assy-IN 9601388012 9601388012 9601388012 9601388012 9601388012
169 Cross Flow Fan Assy 9368586003 9368586003 9368586003 9368586003 9368586003
178-1 Rubber (Motor) 9368575007 9368575007 9368575007 9368575007 9368575007
199 Step Motor 9900020019 9900020019 9900020019 9900020019 9900020019
220 Water Plate ––––– ––––– ––––– ––––– 9368569006
233 Power Transformer 9900069018 9900069018 9900069018 9900069018 9900069018
236 Controller PCB Assy 9704607065 9704607287 9704607324 9704607300 9704607096
240 Remote Control Unit 9371190020 9371190013 9371190020 9371190013 9371190013
321 Flap 9368544010 9368544010 9368544010 9368544010 9368544010
329 Coupling Pipe Assy 9369241000 9369241000 9369241000 9369241000 9371333014
338 Motor Holder-A 9368550004 9368550004 9368550004 9368550004 9368550004
338-1 Motor Holder-B 9368551001 9368551001 9368551001 9368551001 9368551001
338-2 Motor Holder-C 9368769000 9368769000 9368769000 9368769000 9368769000
385 Indicator PCB Assy 9702307011 9702307011 9702307011 9702307011 9702307011
401 Wall Hook Bracket 9368579005 9368579005 9368579005 9368579005 9368579005
408 Louver Link 9368562007 9368562007 9368562007 9368562007 9368562007
425 Earth Plate 9368580001 9368580001 9368580001 9368580001 9368580001
428 Screw Cover 9368576011 9368576011 9368576011 9368576011 9368576011
435 Louver Spring 9368613006 9368613006 9368613006 9368613006 9368613006
473 Pipe Holder 9368565008 9368565008 9368565008 9368565008 9368565008
473-1 Cord Holder 9368566005 9368566005 9368566005 9368566005 9368566005
506 Louver Rod 9368561017 9368561017 9368561017 9368561017 9368561017
514 Control Box 9368543006 9368543006 9368543006 9368543006 9368543006
522-1 Sector Gear 9368556006 9368556006 9368556006 9368556006 9368556006
522-2 Pinion Gear 9368557003 9368557003 9368557003 9368557003 9368557003
522-3 Flap Spring 9368612009 9368612009 9368612009 9368612009 9368612009
557 Diffuser Spring 9368587000 9368587000 9368587000 9368587000 9368587000
564 Bypass Pipe-A Assy ––––– ––––– ––––– ––––– 9371323015
564-2 Bypass Pipe-C Assy 9369479007 9369479007 9369479007 9369479007 9371619019
574-1 Evaporator Support-R 9368549008 9368549008 9368549008 9368549008 9368549008
Ref.
No.
Description
ASG18ABAJ ASG18RBAJ
Ord.
Q'ty
Part No.
ASG24RBAJ ASG30RBAJ
