2004.10.19
- 8 -
Error
The OPERA
TION,
TIMER and SWING lamps operate as f
ollows according to the error contents.
Error displa
y
OPERA
TION TIMER
SWING
(RED)
(GREEN)
(ORANGE)
Error contents
Indoor unit circuit board error
Indoor unit room temperature sensor wire
opened
Indoor unit room temperature sensor wire
shor
t circuited
Indoor unit piping sensor wire opened
Indoor unit piping sensor wire shor
t circuited
Indoor unit f
an error
2 times
2 times
3 times
3 times
6 times
:
F
ast flashing
:
Slow flashing
:
Off
ERR
OR CONTENTS
8
10
