Specifications
 Frequency Response: 16Hz to 36kHz, +/- 1dB
 Sensitivity: 91 dB 1 watt 1 meter
 Controls (on amplifier): Gain, Phase,
low-pass, high-pass
 Controls (on speaker): Rear Tweeters (+/- 1 dB)
Midrange (+/- 0.75 dB)
 Input Impedance: 4 ohms (nominal)
33K ohms (amplifier)
 HF Transducers (per side): 26 Genesis 1” Circular Ribbon
Tweeters (20 front, 6 rear)
 Midrange Transducer (per side): Single 75” Ribbon
 LF Transducers (per side): Six Genesis 12” woofers with
ribbed aluminum cones
 Amplifier Power Rating: Six channels per side
@400 watts each
 Amplifier Inputs: 1pair XLR (balanced)
1pair RCA (single ended)
 Dimensions:
Mid/Tweeter Wing: H 90” x W 41.5” x D 5” each
Woofer Tower: H 90” x W 15.5” x D 19” each
Amplifier: H 10” x W 12” x D19” each
Crossover: H 3” x W 6” x D 8” each
 Weight: 1,250 lbs (568kg) per side
70 lbs (32kg) amplifier per side
 Finish: Rosewood/Corian

Genesis 1.1 Specifications

Frequency and Sensitivity

frequency response	16Hz to 36kHz, +/- 1dB
sensitivity	91 dB 1 watt 1 meter

Transducers

HF transducers per side	26 Genesis 1” Circular Ribbon Tweeters (20 front, 6 rear)
midrange transducer per side	Single 75” Ribbon
LF transducers per side	Six Genesis 12” woofers with ribbed aluminum cones

Power and Impedance

input impedance	4 ohms (nominal), 33K ohms (amplifier)
amplifier power rating	Six channels per side @400 watts each
amplifier inputs	1 pair XLR (balanced), 1 pair RCA (single ended)

Weight and Dimensions

weight per side	1, 250 lbs (568kg)
weight amplifier per side	70 lbs (32kg)
mid/tweeter wing dimensions	H 90” x W 41.5” x D 5” each
woofer tower dimensions	H 90” x W 15.5” x D 19” each
amplifier dimensions	H 10” x W 12” x D19” each
crossover dimensions	H 3” x W 6” x D 8” each
