1.2 Placement of the Genesis 1.1 Loudspeaker
The G1.1 requires a large room in order to give the speaker ample
space from the walls so that it can perform at its best. A typical room
size is 29 ft x 48 ft with 12 ft ceilings.
A good starting position for the midrange/tweeter panels is 15 feet into
the room as measured from the front wall (the wall behind the
speakers which you look at as you are seated listening to the
speakers) to the face of the speakers. You will want to sit 18 feet away
as measured from the face of the speakers to the ears, and have
approximately 15 feet (if available) behind you to the rear wall. Place
the column of tweeters on the inside, and position the mid/tweeter
panels so that the centers of the tweeters are 6 feet 10 inches apart.
Next, position the woofer towers just to the outside of, and behind the
mid/tweeter wings. Having the woofers diagonally six feet behind the
midrange/tweeters work well. Placing the woofer towers asymmetric in
the room results in a smoother bass response than if the woofers are
symmetric. If you have a much more space and a wider room, the
woofer towers can be also be positioned outside the mid/tweeter
wings in an arc such that the center of the woofer cone and the
tweeters are equidistant from the listeners.
Tweeters
6’ to 8’
1/3 or 20% 1/3 or 20%
Typical room placement: Place speakers and
listeners about 1/3 of the way into the room
