Genesis 1.2 User Manual

Ver 1.0
31
~ÄëçäìíÉ=ÑáÇÉäáíó
Specifications
 Frequency Response: 16Hz to 36kHz, +/- 1dB
 Sensitivity: 91 dB 1 watt 1 meter
 Controls (on bass amplifiers): Gain, Phase,
low-pass, high-pass
 Controls (on crossover): Rear Tweeters (+/- 1 dB)
Midrange (+/- 0.75 dB)
 Input Impedance: 4 ohms (nominal)
 HF Transducers (per side): 26 Genesis 1” Circular Ribbon
Tweeters (20 front, 6 rear)
 Midrange Transducer (per side): Single 75” Ribbon
 LF Transducers (per side): Twelve Genesis 12” woofers
with ribbed aluminum cones
 Bass Amplifier Power Rating: Six channels per side
@400 watts each
 Bass Amplifier Inputs: 1 pair XLR (balanced) for
Servo-Bass Interconnect
 Dimensions:
Mid/Tweeter Wing: H 90” x W 41.5” x D 5” each
Crossover: H 3” x W 6” x D 8” each
Woofer Tower: H 90” x W 15.5” x D 19” each
Amplifier: H 11” x W 12” x D13” stack
Power Transformer: H 6” x W 10” x D 12” each
 Weight (per side): approx.1,000 lbs (450kg)
 Finish: Rosewood/Corian

Genesis 1.2 Specifications

Audio Specifications

frequency response	16Hz to 36kHz, +/- 1dB
sensitivity	91 dB 1 watt 1 meter
input impedance	4 ohms (nominal)
bass amplifier power rating	Six channels per side @400 watts each

Transducers

HF transducers	26 Genesis 1” Circular Ribbon Tweeters (20 front, 6 rear)
midrange transducer	Single 75” Ribbon
LF transducers	Twelve Genesis 12” woofers with ribbed aluminum cones

Weight and Dimensions

weight per side	approx.1, 000 lbs (450kg)
mid/tweeter wing dimensions	H 90” x W 41.5” x D 5” each
woofer tower dimensions	H 90” x W 15.5” x D 19” each
