Ver 1.0
8
~ÄëçäìíÉ=ÑáÇÉäáíó
For some rooms, there may not be enough space and you will have to
adjust as you see fit. In a smaller room, the speakers can be just 20%
of the way into the room, and the listening position can then be 20%
from the rear wall. (see the diagram above). If you have to sit less
than 12 feet in front of the speakers, you have too small a room to
accommodate the Genesis 1.2’s.
1.3 Servo-Controlled Bass Amplifier System
The 12-channel Genesis Servo-Controlled Bass Amplifier comes in a
total of ten (10) modules. It comprises:
1) Left and Right Control Modules with left and right balanced
inputs and a pair of control outputs (each Control Module is
built as a dual-stereo unit, but only one input is used in each).
The Control Modules have a standard IEC power input.
2) Two left-channel Servo-Amplifier Modules with three 50-amp
Speakon™ outputs per module and a blue PowerCon™ power
input.
3) Two right-channel Servo-Amplifier Modules with three 50-amp
Speakon™ outputs per module and a blue PowerCon™ power
input.
4) Four 2kVA Power Transformer Modules each with a grey
PowerCon output (one per amplifier module)
Cables and accessories included in the package are:
1) Four Power Umbilicals with a grey PowerCon™ at one end
and a blue PowerCon™ at the other end
2) Four Control Interface Cables (CIC) with 7-pin Neutrik™
connectors at each end.
3) Two Servo-Bass Interconnect Cables (SBI) left and right with
bananas (optionally spades) at one end and Neutrik XLR
connectors at the other end.
4) Two amplifier acoustic suspensions, one for each stack of
amplifiers.
5) Six power cords are also included (the user is encouraged to
use their preferred brand of high-end power cables and
connectors)
In the typical configuration, the 12-channel Servo-Controlled Bass
Amplifier is placed in two stacks – each stack near the woofer tower
