Genesis XM series User Manual

8
XM Series UPS – GENERAL INFORMATION
Electrical Inputs:
Genesis XM Series UPS is a Single Phase Input – Single Phase Output System with an Input
Range of 160VAC – 285VAC.
In-built AVR regulates extreme voltage to deliver an output between – 200VAC to 255VAC,
which is suitable for most of the equipments including Computers.
Genesis XM Series UPS will switch over to battery below 160VAC and above 285VAC input.
DC Input is from storage Battery. DC Voltage is mentioned at the back of the UPS Systems.
DC Voltage determines the number of Batteries to be connected.
Example: DC – 48V
Voltage Per Battery – 12V
No. of Batteries = 48/12 = 4 Nos.
The XM Series UPS AC Output conform to the conventional power in order to run locally
available appliances.230 Volts at a frequency of 50 Hertz (cycles per second).

Genesis XM series Specifications

General

Brand	Genesis
Model	XM series
Category	UPS
Language	English
