(2)Check gasket inner dia of
slide driving plate: limit
of use : change it over 24.1mm.
(3)Check the driving pulley
surface wearing condition.
(4)Check the outer diameter of the
contact surface of the movable
driving plate.
limit of use : change it
below 23.94mm.
9.Assemble the slide driving plate.
(1)Clean up the inside surface of slide
driving plate, then assemble the
roller.
(2)Assemble the ramp plate.
(3)Other procedure refers to the
opposite procedure of
disassembling.
