22
BE24
UK
14 - FLASHING LIGHT SIGNALS SUMMARY
Meaning
Signal Effect
Opening
Edge intercepted in stand-by
in presence of START command
Edge intercepted in pause in presence of
START command or at the closing beginning
Low Battery before closing (21V).
Low Battery before opening or closing(16V).
0,8s ON, 0,8s OFF continuous
3 slow flashings
3 slow flashings
4 seconds slow flashing
4 seconds slow flashing
The gate is opening
Blocked closed door
Blocked open door
Blocked open door
Blocked door
15 - TROUBLESHOOTING
The gate does not move after a START
command.
ŸCheck that L3, L4 and L5 are off; if not, check the devices connected to
terminals 19-20-21.
ŸCheck fuses.
ŸCheck that the battery voltage is not below 22VDC.
ŸIf L7 is blinking fast, learning procedure must be executed.
The gate moves slowly during opening.
The first maneuvre after a power failer is slowed and with automatic logic.
The gate does not fully open/close.
Check the motor and encoder connections.
The gate moves slowly.
Check the control board is not running on battery.
Transmitter range is short.
Check terminals 26-27 screws are tight.
Check and replace transmitter battery.
Photo 2 intercepted in stand-by
in presence of START command
5 fast flashings
When released it opens
Closing
0,4s ON, 0,4s OFF continuous
The gate is closing
