Gigabyte B450M DS3H WIFI User Manual

CPU  AMD Socket AM4, support for:
AMD Ryzen
™
5000 Series Processors/
AMD Ryzen
™
5000 G-Series Processors/
AMD Ryzen
™
4000 G-Series Processors/
3rd Generation AMD Ryzen
™
processors/
2nd Generation AMD Ryzen
™
processors/
1st Generation AMD Ryzen
™
processors/
2nd Generation Ryzen
™
with Radeon
™
Vega Graphics processors/
1st Generation Ryzen
™
with Radeon
™
Vega Graphics processors/
Athlon
™
with Radeon
™
Vega Graphics Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset  AMD B450
Memory  4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
 Dual channel memory architecture
 Support for DDR4 2933/2667/2400/2133 MT/s memory modules
 Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
 Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
 Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
 Integrated Graphics Processor:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
(Note)
* Support for HDMI 2.0 version and HDCP 2.2.
(Note)
 Maximum shared memory of 16 GB
Audio  Realtek
®
Audio CODEC
 High Denition Audio
 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To
congure 7.1-channel audio, access the audio software for audio settings.
 Support for S/PDIF Out
LAN  Realtek
®
GbE LAN chip (1 Gbps/100 Mbps)
Wireless
Communication
Module
 Wi-Fi module
- WIFI 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 4.2
- Support for 11ac wireless standard and up to 433 Mbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots  1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 3.0 standard.)
 1 x PCI Express x16 slot, running at x1 (PCIEX1_2)
 1 x PCI Express x1 slot
(The PCIEX1_1 and PCIEX1_2 slots conform to PCI Express 2.0 standard.)
(Note) Actual support may vary by CPU.
2-2 ProductSpecications
- 7 -

Gigabyte B450M DS3H WIFI Specifications

General

Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen
Supported processor sockets	Socket AM4
Maximum number of SMP processors	1
Maximum internal memory supported by processor	128 GB
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3600 MHz
Supported memory clock speed (max)	3600 MHz
Supported memory module capacities	4GB, 8GB, 16GB, 32GB
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN controller model	Realtek RTL8821CE
Ethernet interface type	Gigabit Ethernet
USB 2.0 connectors	2
Number of Parallel ATA connectors	0
USB connector type	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Number of storage drives supported	5
Supported storage drive interfaces	M.2, SATA III
Bundled software	Norton Internet Security, cFosSpeed
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	16000 MB
Parallel processing technology support	Not supported
Audio chip	Realtek ALC887
Component for	PC
Product color	Brown
Power source type	ATX
Motherboard chipset	AMD B450
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 x64, Windows 7 x64
Warranty period	3 year(s)
Battery type	CR2032
Battery weight	3 g
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Country of origin	China
Quantity per shipping (inner) case	1 pc(s)
Package width	265 mm
Package height	54 mm
Package weight	950 g

Weight and Dimensions

Height	35 mm
