Gigabyte B450M S2H User Manual

- 4 -
B450M S2H Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 B450M S2H motherboard 5 Two SATA cables
5 Motherboard driver disk 5 I/O Shield
5 User's Manual
KB_MS
CPU_FAN
SYS_FAN1
LED_CPU
ATX
B450M S2H
AUDIO
DDR4_2 DDR4_1
BAT
ATX_12V
AMD
B450
R_USB30_1
HDMI
CODEC
M_BIOS
VGA
DVI
PCIEX16
PCIEX1_1
PCIEX1_2
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB30
CI
SPEAKER
F_USB1
F_PANEL
F_USB2
TPM
SPDIF_O
SATA3
0 1 2
USB_LAN
Socket AM4
R_USB30_2
3
CLR_CMOS
F_AUDIO
M2A_SOCKET
806042
SATA3

Gigabyte B450M S2H Specifications

General

Form Factor	Micro ATX
Chipset	AMD B450
CPU Socket	AM4
Memory Type	DDR4
Memory Slots	2
Max Memory	32 GB
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4
M.2 Slots	1
USB Ports	4 x USB 3.1 Gen 1, 6 x USB 2.0
Video Outputs	1 x DVI-D, 1 x HDMI
Audio	Realtek ALC887
LAN	Realtek GbE LAN
RAID Support	RAID 0, RAID 1, RAID 10
Memory Speed	2933/2667/2400/2133 MHz
Expansion Slots	1 x PCIe x16
