Gigabyte B450M S2H User Manual

Internal
Connectors
 1 x 24-pin ATX main power connector
 1 x 8-pin ATX 12V power connector
 1 x CPU fan header
 1 x system fan header
 1 x M.2 Socket 3 connector
 4 x SATA 6Gb/s connectors
 1 x front panel header
 1 x front panel audio header
 1xS/PDIFOutheader
 1xCPUcoolerLEDstrip/RGBLEDstripheader
 1 x USB 3.1 Gen 1 header
 2 x USB 2.0/1.1 headers
 1xTrustedPlatform Module(TPM) header (2x6pin,for the GC-TPM2.0_S
moduleonly)
 1 x speaker header
 1 x Clear CMOS jumper
 1 x chassis intrusion header
Back Panel
Connectors
 1 x PS/2 keyboard port
 1 x PS/2 mouse port
 1xD-Subport
 1xDVI-Dport
 1xHDMIport
 4 x USB 3.1 Gen 1 ports
 2 x USB 2.0/1.1 ports
 1xRJ-45port
 3 x audio jacks
I/O Controller  iTE
®
I/O Controller Chip
Hardware
Monitor
 Voltage detection
 Temperature detection
 Fan speed detection
 Overheating warning
 Fan fail warning
 Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you
install.
BIOS  1x128Mbitash
 Use of licensed AMI UEFI BIOS
 PnP1.0a,DMI2.7,WfM2.0,SMBIOS2.7,ACPI5.0
- 7 -
