1-2 Motherboard Block Diagram
(Note) Actual support may vary by CPU.
j Only for B650 AORUS ELITE AX ICE.
k Only for B650 AORUS ELITE AX V2.
4 USB 3.2 Gen 1
USB 3.2
Gen 1 Hub
LAN
RJ45
x1
Realtek
®
2.5GbE LAN
CPU CLK+/- (100 MHz)
DDR5 5200/4800/4400 MT/s
4 SATA 6Gb/s
(SATA3 0~3)
eSPI
Bus
SPI
Bus
iTE
®
Super I/O
4 USB 2.0/1.1
1 USB Type-C
®
,
with USB 3.2 Gen 2x2 support
BIOS
TPM
PCI Express 5.0
(Note)
Bus
USB 2.0
Hub
PCI Express 3.0 Bus
1 USB Type-C
®
,
with USB 3.2 Gen 2 support
1 M.2 Socket 3
(M2A_CPU)
1 HDMI
2 USB 3.2 Gen 2 Type-A
4 USB 2.0/1.1
PCIe x4
AMD Chipset
x1
M.2 WIFIjk
3 USB 3.2 Gen 1
x4
x16
1 PCI Express x16
AM5 CPU
CODEC
1 DisplayPort
PCI Express 4.0 Bus
1 M.2 Socket 3
(M2B_CPU)
x4
Line Out
MIC
Line In
2 PCI Express x1
x1
PCI Express 4.0 Bus
1 M.2 Socket 3
(M2C_SB)
x4
