GA-8I945PL-G Motherboard - 10 -
English
CPU Supports Intel
®
Pentium
®
D / Pentium
®
4 LGA775 CPU
(Note 1)
Supports 800/533MHz FSB
L2 cache varies with CPU
Chipset Northbridge: Intel
®
945PL Express Chipset
Southbridge: Intel
®
ICH7
Supported on the Win 2000/XP operating systems
Memory 4 DDR II DIMM memory slots (supports up to 2GB memory)
Supports 1.8V DDR II DIMM
Supports dual channel DDR II 533
(Note 2)
/400 DIMM
Slots 1 PCI Express x 16 slot
2 PCI Express x 1 slot
3 PCI slots
IDE Connections 1 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of 2
IDE devices(IDE1)
- Supported on the Win 2000/XP operating systems
2 IDE connection (UDMA 33/ATA 66/ATA 100/ATA 133), compatible with
RAID, allows connection of 4 IDE devices(IDE2,IDE3)
(Note3)
FDD Connections 1 FDD connection, allows connection of 2 FDD devices
Onboard SATA 3Gb/s 4 SATA 3Gb/s connections
Supported on the Win 2000/XP operating systems
Peripherals 1 parallel port supporting Normal/EPP/ECP mode
1 Serial port (COMA)
8 USB 2.0/1.1 ports (rear x 4, front x 4 via cable)
1 front audio connector
1 PS/2 keyboard port
1 PS/2 mouse port
Onboard LAN Onboard Broadcom 5789 chip (10/100/1000 Mbit)
1 RJ 45 port
Supported on the Win 2000/XP operating systems
(Note 1) For further CPU support information, please go to GIGABYTE's website.
(Note 2) Memory frequency will be reduced from 533MHz down to 400Mhz when
a. use DDRII1 / DDRII2 at the same time.
b. use DDRII3 / DDRII4 at the same time.
c. use DDRII1 / DDRII2 / DDRII3 / DDRII4 at the same time.
(please refer to page15)
(Note 3) Only support ATAPI mode for HDD.
1-2 Feature Summary
