Gigabyte GA-8I945PL-G User Manual

GA-8I945PL-G Motherboard - 18 -
English
1-7 Connectors Introduction
1) ATX_12V
2) ATX (Power Connector)
3) CPU_FAN
4) SYS_FAN
5) FDD
6) IDE1/IDE2/IDE3
7) SATAII0 / SATAII1 / SATAII2 / SATAII3
8) F_AUDIO
9) PWR_LED
Center/Subwoofer Speaker Out
The default Center/Subwoofer Speaker Out jack. Center/Subwoofer speakers can be connected to
Center/Subwoofer Speaker Out jack.
Side Speaker Out
The default Side Speaker Out jack. Surround side speakers can be connected to Side Speaker Out
jack.
In addition to the default speakers settings, the ~ audio jacks can be reconfigured to perform
different functions via the audio software. Only microphones still MUST be connected to the de-
fault Mic In jack ( ) . Please refer to the 2-/4-/6-/8- channel audio setup steps for detailed software
configuration information.
10) F_PANEL
11) CD_IN
12) SPDIF_I
13) F_USB/GREEN_USB
14) RF_ID
15) CI
16) CLR_CMOS
17) BAT
6
7
5
15
4
8
13
12 13
11
1
3
2
10
14
16
6
9
17
