1-7 Internal Connectors
Readthefollowingguidelinesbeforeconnectingexternaldevices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V
2) ATX
3) CPU_FAN
4) SYS_FAN1/2
5) ASATA3 0/1
6) SATA3 0/1/2/3
7) BAT
8) M2F_ 32G
9) F_PANEL
10) SPDIF_O
11) F_ AUDIO
12) F_USB30
13) F_USB1/F_USB2
14) TPM
15) COMA/COMB
16) LPT
17) CLR_CMOS
1
2
3
1216
8
5
13 9
4
17
11 14
10
4
7
6
15
- 12 -
