Gigabyte GA-EP35-DS3P User Manual

GA-EP35-DS3P Motherboard - 22 -
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the
power cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable
has been securely attached to the connector on the motherboard.
1) ATX_12V_2X
2) ATX
3) PCIE_12V
4) PHASE LED
5) CPU_FAN
6) SYS_FAN1/SYS_FAN2
7) PWR_FAN
8) NB_FAN
9) FDD
10) IDE
11) SATAII0/1/2/3/4/5
12) GSATAII0/1
13) PWR_LED
14) BAT
15) F_PANEL
16) F_AUDIO
17) CD_IN
18) SPDIF_O
19) SPDIF_IN
20) F_USB1/F_USB2
21) F1_1394
22) COMA
23) LPT
24) CLR_CMOS
25) CI
2
1 4
20
8
10
9
1521
16
11
6 3
14
7
22
24
5
12
18
17
19 1323 6
25
