GA-EP45T-UD3LR Motherboard - 10 -
1-2 Product Specifications
CPU  Support for an Intel
®
Core
TM
2 Extreme processor/
Intel
®
Core
TM
2 Quad processor/Intel
®
Core
TM
2 Duo processor/
Intel
®
Pentium
®
Dual-Core processor/Intel
®
Celeron
®
processor
in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
 L2 cache varies with CPU
Front Side Bus  1600/1333/1066/800 MHz FSB
Chipset  North Bridge: Intel
®
P45 Express Chipset
 South Bridge: Intel
®
ICH10R
Memory  4 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
 Dual channel memory architecture
 Support for DDR3 2200/1600/1333/1066/800 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio  Realtek ALC888 codec
 High Definition Audio
 2/4/5.1/7.1-channel
 Support for S/PDIF In/Out
 Support for CD In
LAN  1 x Realtek 8111C chip (10/100/1000 Mbit)
Expansion Slots  1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
 4 x PCI Express x1 slots
 2 x PCI slots
Storage Interface  South Bridge:
- 6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5 and RAID 10
 JMicron 368 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
 iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
USB  Integrated in the South Bridge
 Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)

Gigabyte GA-EP45T-UD3LR Specifications

General

Memory voltage	1.5 V
Number of memory slots	4
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
USB 2.0 connectors	12
Power fan connector	Yes
Number of SATA connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	8
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC888
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows Vista, XP
BIOS type	AWARD
RAID levels	0, 1, 10
LAN controller	Realtek RTL8111C
Networking features	10/100/1000 Mbit
Trial software	Norton Internet Security

Weight and Dimensions

Depth	210 mm
Width	305 mm
