Gigabyte GA-P67A-UD4-B3 User Manual

Hardware Installation - 10 -
1-2 Product Specications
CPU

Support for Intel
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/
Intel
®
Celeron
®
processors in the LGA1155 package
(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU
Chipset

Intel
®
P67 Express Chipset
Memory

4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.

Dual channel memory architecture

Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules

Support for non-ECC memory modules

 SupportforExtremeMemoryProle(XMP)memorymodules


 ( Go to GIGABYTE's website for the latest supported memory speeds and
memory modules)
Audio
   
Realtek ALC892/889 codec

HighDenitionAudio

2/4/5.1/7.1-channel

Support for Dolby
®
Home Theater
    
Support for S/PDIF Out
LAN

1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots

1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.

1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is
populated, the PCIEX16 slot will operate at up to x8 mode.

3 x PCI Express x1 slots
(All PCI Express slots conform to PCI Express 2.0 standard.)

2 x PCI slots
Multi-Graphics

Support for ATI CrossFireX
™
/NVIDIA SLI technology
Technology
* The PCIEX16 slot operates at up to x8 mode when ATI CrossFireX
™
is enabled.
Storage Interface

Chipset:
- 2 x SATA 6Gb/s connectors (SATA3_0, SATA3_1) supporting up to 2 SATA
6Gb/s devices
- 4 x SATA 3Gb/s connectors (SATA2_2, SATA2_3, SATA2_4, SATA2_5)
supporting up to 4 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10
* When a RAID set is built across the SATA 6Gb/s and SATA 3Gb/s channels, the
system performance of the RAID set may vary depending on the devices being con-
nected.

Marvell 88SE9128 chip:
- 2 x eSATA 6Gb/s connectors on the back panel supporting up to 2 SATA
6Gb/s devices
- Support for SATA RAID 0 and RAID 1

Gigabyte GA-P67A-UD4-B3 Specifications

General

Brand	Gigabyte
Model	GA-P67A-UD4-B3
Category	Motherboard
Language	English
