- 6 -
GV-N500 Series Graphics Accelerator
2. Hardware Installation
2.1. Board Layout
DVI-I Connector 1
DVI-I
Connector 1
DVI-I
Connector 2
DVI-I Connector 2
Mini HDMI Connector
Mini HDMI
Connector
Digital LCD Monitor
Digital LCD Monitor
DVI Output
DVI Output
HDMI TV
SLI Connector
Power Connectors
