9.3 SOC INDICATION
SYMBOL BATTERY VOLTAGE
≥ 12.8 / 25.6 V
≥ 12.6 / 25.2 V to 12.8 / 25.6 V
≥ 11.8 / 23.6 V to 12.6 / 25.2 V
≥ 11.0 / 22.0 V to 11.8 / 23.6 V
≤ 11.0 / 22.0 V
Note there are two dierent system voltages that can be supported: 12V and 24V. If the voltage read from the controller is
less than 18V the system voltage shall be 12V. If the voltage is greater than 18V the system voltage shall be 24V.
BLUETOOTH WIRELESS TECHNOLOGY
