It is advisable to use Agip Blasia S 220 oil
First oil change after the first 50-60 work hours.
Change oil after every 150 hours. Amount needed is around 2 kg.
Oil drain: plug A fig.4.
5.3 REGISTRATIONS AND CHECKS
5.3.1 Registering clutch lever
From time to time check the clutch lever. If the play is excessive, register with
screw E fig.8
5.3.2 Registering the throttle
To register throttle lever, adjust with the registration screw on the end of the
throttle wire at the engine.
5.3.3 Adjusting wheel release
Lever n.9 fig.1 must have a take-up of 2 mm before beginning to release the
wheel. Reset this play with screw n.11 fig.1.
6 MAJOR FEATURES
6.1 SPEED
SPEED CHART
In km/h - with engine at 3600 Rpm
(Figures are indicative)
Reverser Forward Reverse
Gears
Wheels
1st 2nd 3rd 4th 1st 2nd 3rd
6x6” (1) 1.7 3.3 6.0 1.5 3.0 (3)
4.00-8" (1) 1.7 3.3 6.0 1.5 3.0 (3)
4.00-8" (2) 2.0 3.2 4.5 8.6 1.4 2.2 3.2
4.0-10" (2) 2.2 3.5 4.8 9.3 1.6 2.4 3.4
16x6.50-8" (2) 2.1 3.3 4.6 8.8 1.5 2.3 3.3
18x6.50-8"
softrac (2)
2.2 3.5 4.8 9.3 1.6 2.4 3.4
21x11.00-8" (2) 2.6 3.9 5.5 10.6 1.8 2.8 3.9
5.0x10" (2) 2.5 3.8 5.4 10.3 1.7 2.7 3.8
4.00x8" (4) 3.2 4.5 8.5 3.4
6x6” (4) 3.2 4.5 8.5 3.4
4.0x10” (1) 1.9 3.8 6.8 1.7 3.5 (3)
(1) Only for FC 3+2
(2) Only for FC Professional
(3) Gear blocked in reverse.
(4) Only for FC
